GRAND RAPIDS, Mich., Sept. 8, 2026 /PRNewswire/ -- What are the most common mistakes in molded part design, and how can they be avoided? According to a HelloNation article, small details in design often determine whether plastic injection molding runs smoothly or encounters costly setbacks. Ryan Eggleston of UTP Solutions dbu-Medi-Tec Plastics in Grand Rapids explains how careful attention to ribs, draft angles, and wall thickness can prevent defects and improve production efficiency.

The article makes clear that molded part design is just as important as the molding process itself. Poor choices at the design stage can cause delays, raise costs, and reduce product quality. Eggleston emphasizes that avoiding common pitfalls allows manufacturers to produce stronger, more reliable parts at lower overall expense.

One of the most frequent issues is improper rib design. Ribs are used to reinforce parts without adding excess wall thickness. However, when ribs are too thick at the base, they create sink marks and warpage as different sections cool unevenly. The HelloNation article recommends that rib thickness stay at about half the adjoining wall. This proportion prevents surface defects while maintaining structural strength. Ryan Eggleston notes that proper rib design supports both durability and appearance.

Draft angles represent another critical factor. Without draft, molded parts often stick inside the tool, requiring extra force for removal. This slows down production, increases wear on molds, and risks part damage. Even a small draft angle helps parts release smoothly. The article explains that while a one-degree draft may be sufficient in some cases, more complex geometries often benefit from larger angles. Eggleston stresses that including draft from the start reduces maintenance costs and keeps cycle times consistent.

The third major area is wall thickness. When walls are uneven, thicker sections cool more slowly than thinner ones, leading to internal stresses, distortion, voids, or weak spots. Consistent wall thickness allows resin to flow evenly through the mold, producing stronger, more reliable components. If variation is unavoidable, gradual transitions should replace sudden changes to maintain flow and reduce stress concentrations. Eggleston highlights that designing for uniform wall thickness is one of the simplest and most effective ways to avoid injection molding defects.

Together, rib proportions, draft angles, and wall thickness may seem like small details, but they have a significant impact on manufacturing outcomes. Addressing them early in the design phase prevents costly rework, lowers scrap rates, and keeps schedules on track. The HelloNation article notes that collaboration between designers and mold makers helps catch potential issues before tooling is built, saving both time and money.

Thoughtful molded part design also improves material efficiency. Optimizing ribs and walls reduces the amount of resin required without sacrificing performance. This lowers costs while supporting sustainability goals by reducing waste. Small adjustments to draft angles can extend the life of tooling as well, since smoother part release causes less wear on mold surfaces. Eggleston adds that these benefits compound across large production runs, creating significant savings over time.

While simulation software can help predict flow, cooling, and stress, the article cautions that it cannot replace sound design principles. Established guidelines such as rib-to-wall ratios, draft requirements, and uniform wall thickness remain the most reliable ways to ensure success. Experienced mold designers bring valuable expertise to this process, refining geometry to fit both function and manufacturability. Eggleston underscores that the most reliable projects rely on proven fundamentals supported by expert input.

Ultimately, the HelloNation article concludes that molded part design determines the efficiency, cost, and reliability of injection molding. Sink marks, sticking parts, and warpage are not inevitable. They can be prevented by following best practices and addressing potential issues before tooling begins. Eggleston emphasizes that thoughtful design not only reduces risk but also ensures that finished parts meet both performance and aesthetic requirements.

The lesson is straightforward: smarter design leads to better results. A few careful decisions at the beginning of a project can prevent expensive setbacks and keep production moving smoothly. Ryan Eggleston's perspective reinforces that in injection molding, attention to detail in molded part design is the fastest path to reliable outcomes.

The full article, Avoiding Common Mistakes in Molded Part Design, features the expertise of Ryan Eggleston, Manufacturing Expert with UTP Solutions dbu-Medi-Tec Plastics, as presented in HelloNation.
